Extreme Clutch

SKU:KMZ18521-2EL

Xtreme Motorsport 200mm twin plate

The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.

The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).

Product Features:

• Torque capacity 1200Nm
• Kit contains everything you need for a successful installation + accessories
• Rigid driven discs (individual hubs)
• Push type billet alloy cover
• 4140 Chromoly pressure & intermediate plates
• Hardened steel wear posts
• Low inertia
• Serviceable components
• SFI certified design

Clamping Force	1000kg
Torque Rating	1200Nm
Bearing Contact Diameter	44-52mm
Bearing Load (@ 48mm)	218kg
Release Travel Required	6mm
Assembly Mass (without flywheel)	7kg
Disc Set Static Mass	1.75kg
Friction Thickness New	7mm (0.275")
Friction Thickness Worn	6.48mm (0.255")

Applications: - MAZDA/RX-7 II (FC)/1.3 (FC3S. FC1031)/1985.11-1989.04/RE13B 1308 Petrol 110 kW 150 BHP (1985.11 - 1989.04) , \n - MAZDA/RX-7 II (FC)/1.3 Turbo (FC3S. FC1031)/1987.06-1989.11/RE13B 1308 Petrol 133 kW 181 BHP (1987.06 - 1989.11) , \n - MAZDA/RX-7 II (FC)/1.3 Turbo (FC3S. FC1031)/1989.03-1991.12/RE13B 1308 Petrol 147 kW 200 BHP (1989.03 - 1991.12) , \n - MAZDA/RX-7 II Cabriolet/1.3 (FC1032)/1988.01-1992.06/13B 1308 Petrol 110 kW 150 BHP (1988.01 - 1992.06) , \n - MAZDA/RX-7 II Cabriolet/1.3 Turbo (FC1032)/1989.03-1991.12/13B-MSP 1308 Petrol 147 kW 200 BHP (1989.03 - 1991.12) ,
