Extreme Clutch

SKU:KTY18521-2E

Xtreme Motorsport 184mm twin plate

Designed for high powered circuit, time attack or gymkhana applications, the Xtreme 184mm Race Clutch offers quick shift times and a lightweight construction.

The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.

Product Features:

• Push type billet alloy cover
• 4140 Chromoly pressure plate
• Hardened steel wear posts
• High and low ratio pressure plate options
• Low inertia
• Serviceable components
• SFI certified design

Replacement Parts
Light Diaphragm Alloy Hat Assembly (2.6mm)	185-10B-PP-L	Heavy Diaphragm Alloy Hat Assembly (2.8mm)	185-10B-PP	Pressure Plate Casting	185-10B-PPC	Intermediate Plate	185-10B-IP	Pressure Plate Bolt	BOLT-8X1.125X50	Pressure Plate Washer	WASHER-8MM-C

	Ø184mm Light Diaphragm (2.6mm)	Ø184mm Heavy Diaphragm (2.8mm)
Clamping Force	950kg	1080kg
Torque Rating	1060Nm	1210Nm
Bearing Contact Diameter	44-52mm
Bearing Load (@ 48mm)	210kg	260kg
Release Travel Required	5mm
Assembly Mass (without flywheel)	4.45kg
Disc Set Static Mass	1.1kg
Friction Thickness New	6.35mm (0.250")
Friction Thickness Worn	5.97mm (0.235")

Applications: - TOYOTA/COROLLA/1.8 (ZZE122_)/2005.10-2007.12/1ZZ-FE 1794 Petrol 93 kW 126 BHP (2005.10 - 2007.12) , \n - TOYOTA/COROLLA/1.8 VVTi (ZZE122_)/2001.01-2007.12/1ZZ-FE 1794 Petrol 100 kW 136 BHP (2001.01 - 2007.12) , \n - TOYOTA/COROLLA sedan/1.8 (ZZE122)/2001.11-2006.10/1ZZ-FE 1794 Petrol 100 kW 136 BHP (2001.11 - 2006.10) , \n - TOYOTA/COROLLA Verso/1.8 (ZNR11_)/2004.04-2009.03/1ZZ-FE 1794 Petrol 95 kW 129 BHP (2004.04 - 2009.03) , \n - TOYOTA/COROLLA Wagon/1.8 (ZZE122)/2001.12-2007.12/1ZZ-FE 1794 Petrol 100 kW 136 BHP (2001.12 - 2007.12) , \n - TOYOTA/COROLLA Wagon/1.8 (ZZE122_)/2005.10-2007.12/1ZZ-FE 1794 Petrol 93 kW 126 BHP (2005.10 - 2007.12) , \n - LOTUS/ELISE/1.8/2007-2011/1ZZ-FE 1796 Petrol (2007-2011) ,
