Extreme Clutch

SKU:KTY18527-2E

Xtreme Motorsport 200mm twin plate

The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.

The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).

Product Features:

• Torque capacity 1200Nm
• Kit contains everything you need for a successful installation + accessories
• Rigid driven discs (individual hubs)
• Push type billet alloy cover
• 4140 Chromoly pressure & intermediate plates
• Hardened steel wear posts
• Low inertia
• Serviceable components
• SFI certified design

Clamping Force	1000kg
Torque Rating	1200Nm
Bearing Contact Diameter	44-52mm
Bearing Load (@ 48mm)	218kg
Release Travel Required	6mm
Assembly Mass (without flywheel)	7kg
Disc Set Static Mass	1.75kg
Friction Thickness New	7mm (0.275")
Friction Thickness Worn	6.48mm (0.255")

Passer til følgende biler

Kontrollér model, motor og årgang før bestilling:

• TOYOTA/STARLET/1.3 (EP82)/1989.12-1996.03/4E-FE 1332 Petrol 74 kW 100 BHP (1989.12 - 1996.03)
• TOYOTA/STARLET/1.3 (EP91_)/1996.01-1999.07/4E-FE 1332 Petrol 55 kW 75 BHP (1996.01 - 1999.07)
• TOYOTA/STARLET/1.3 Turbo (EP82_)/1989.12-1995.12/4E-FTE 1332 Petrol 99 kW 135 BHP (1989.12 - 1995.12)

Applications: - TOYOTA/STARLET/1.3 (EP82)/1989.12-1996.03/4E-FE 1332 Petrol 74 kW 100 BHP (1989.12 - 1996.03) , \n - TOYOTA/STARLET/1.3 (EP91_)/1996.01-1999.07/4E-FE 1332 Petrol 55 kW 75 BHP (1996.01 - 1999.07) , \n - TOYOTA/STARLET/1.3 Turbo (EP82_)/1989.12-1995.12/4E-FTE 1332 Petrol 99 kW 135 BHP (1989.12 - 1995.12) ,
