Extreme Clutch

SKU:KGM23589-2E

Xtreme Clutch 230mm twin plate kit

The Xtreme Clutch 230mm Race Clutch is available with either ceramic, organic or carbon friction materials, making these kits ideal for high horsepower and motorsport applications where a high heat capacity is required.

The Xtreme 230mm Race Clutch is the ultimate in clutch solutions with a range like no other. The 230mm range boasts a variety of kits to suit most high horsepower applications for street, circuit, drift or race use. The Xtreme 230mm Race Clutch has been designed, allowing for endless options with clutch operation with internal hydraulic options and pull-push conversions a factoring feature in the 230mm range.

Product Features:

• Torque capacity 1800Nm
• Kit contains everything you need for a successful installation + accessories
• Push type billet alloy cover Low pedal effort
• 4140 Chromoly pressure & intermediate plates
• Chromoly adapter ring
• Low inertia
• Serviceable components
• SFI certified design

	Flat Diaphragm	Rolled Diaphragm
Clamping Force	1300kg	1300kg
Torque Rating	1800Nm	1800Nm
Bearing Contact Diameter	65mm	FLAT BEARING
Bearing Load (@ 48mm)	180kg	150kg
Release Travel Required	7mm	7mm
Assembly Mass (without flywheel)	8.30kg	8.30kg
Disc Set Static Mass	2.25kg	2.25kg
Friction Thickness New	8mm (0.315")	8mm (0.315")
Friction Thickness Worn	7.5mm (0.295")	7.5mm (0.295")

Applications: - HOLDEN/CALAIS sedan (VS)/5.0 i V8/1995.08-1997.06/GMH 308 4987 Petrol 165 kW 224 BHP (1995.08 - 1997.06) , \n - HOLDEN/CALAIS sedan (VS)/5.0 i V8/1997.06-1997.09/GMH 308 4987 Petrol 168 kW 228 BHP (1997.06 - 1997.09) , \n - HOLDEN/CALAIS sedan (VT)/5.0 i V8/1997.09-1999.06/50LB9 4987 Petrol 179 kW 243 BHP (1997.09 - 1999.06) , \n - HOLDEN/CALAIS sedan (VT)/5.0 i V8/1998.04-2000.10/50LB9 4987 Petrol 195 kW 265 BHP (1998.04 - 2000.10) , \n - HOLDEN/CAPRICE sedan (VS)/5.0 i V8/1995.04-1999.06/50LB9 4987 Petrol 168 kW 228 BHP (1995.04 - 1999.06) , \n - HOLDEN/COMMODORE pick-up (VS)/5.0 i V8/1995.04-1996.05/50LB9 4987 Petrol 165 kW 224 BHP (1995.04 - 1996.05) , \n - HOLDEN/COMMODORE pick-up (VS)/5.0 i V8/1996.06-2000.12/50LB9 4987 Petrol 168 kW 228 BHP (1996.06 - 2000.12) , \n - HOLDEN/COMMODORE pick-up (VS)/5.0 i V8/1997.09-2000.12/50LB9 4987 Petrol 179 kW 243 BHP (1997.09 - 2000.12) , \n - HOLDEN/COMMODORE sedan (VS)/5.0 i V8/1995.08-1997.06/50LB9 4987 Petrol 165 kW 224 BHP (1995.08 - 1997.06) , \n - HOLDEN/COMMODORE sedan (VS)/5.0 i V8/1997.06-1997.09/50LB9 4987 Petrol 168 kW 228 BHP (1997.06 - 1997.09) , \n - HOLDEN/COMMODORE sedan (VT)/5.0 i V8/1997.09-1999.06/50LB9 4987 Petrol 179 kW 243 BHP (1997.09 - 1999.06) , \n - HOLDEN/COMMODORE sedan (VT)/5.0 i V8/1998.04-2000.08/50LB9 4987 Petrol 195 kW 265 BHP (1998.04 - 2000.08) , \n - HOLDEN/COMMODORE Wagon (VS)/5.0 i V8/1995.08-1997.09/50LB9 4987 Petrol 167 kW 227 BHP (1995.08 - 1997.09) , \n - HOLDEN/COMMODORE Wagon (VT)/5.0 i V8/1997.09-2002.08/50LB9 4987 Petrol 179 kW 243 BHP (1997.09 - 2002.08) , \n - HOLDEN/STATESMAN sedan (VS)/5.0 i V8/1995.04-1999.06/50LB9 4987 Petrol 168 kW 228 BHP (1995.04 - 1999.06) , \n - HSV/CLUBSPORT sedan (VS)/5.0 i V8/1995.04-1997.08/GMH308 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08) , \n - HSV/CLUBSPORT sedan (VT)/5.0 i V8/1997.01-1999.06/GMH308 4987 Petrol 195 kW 265 BHP (1997.01 - 1999.06) , \n - HSV/CLUBSPORT Wagon (VS)/5.0/1995.04-1997.08/GMH308 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08) , \n - HSV/MALOO (VS)/5.0 i V8/1995.04-1999.05/VU 4987 Petrol 185 kW 252 BHP (1995.04 - 1999.05) , \n - HSV/MALOO (VS)/5.0 i V8/1995.05-2000.10/VU 4987 Petrol 195 kW 265 BHP (1995.05 - 2000.10) , \n - HSV/MANTA sedan (VS)/5.0 i V8/1995.04-1997.08/VU 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08) , \n - HSV/MANTA sedan (VT)/5.0 i V8/1997.09-1999.01/VU 4987 Petrol 195 kW 265 BHP (1997.09 - 1999.01) , \n - HSV/MANTA Wagon (VS)/5.0 i V8/1995.04-1997.08/VU 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08) , \n - HSV/SENATOR sedan (VS)/5.0 i V8/1995.04-1997.08/VU 4987 Petrol 185 kW 252 BHP (1995.04 - 1997.08) , \n - HSV/SENATOR sedan (VT)/5.0 i V8/1997.09-1999.06/VU 4987 Petrol 195 kW 265 BHP (1997.09 - 1999.06) , \n - HSV/SENATOR Wagon (VT)/5.0 i V8/1997.09-2000.08/VU 4987 Petrol 195 kW 265 BHP (1997.09 - 2000.08) , \n - HSV/XU8 sedan (VT)/5.0 i V8/1999.01-1999.06/VU 4987 Petrol 195 kW 265 BHP (1999.01 - 1999.06) ,
