Extreme Clutch

SKU:KHN18521-1E

-1E
	The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.
	Ø184mm Light Diaphragm (2.6mm) Ø184mm Heavy Diaphragm (2.8mm) Clamping Force 950kg 1080kg Torque Rating 535Nm (395ft.lbs) 610Nm (450ft.lbs) Bearing Contact Diameter 44-52mm 44-52mm Bearing Load (@ 48mm) 210kg 260kg Release Travel Required 5mm 5mm Assembly Mass (without flywheel) 3.10kg 3.10kg Disc Set Static Mass 0.6kg Friction Thickness New 6.35mm (0.250") 6.35mm (0.250") Friction Thickness Worn 5.58mm (0.220") 5.58mm (0.220") Product Features: Push type billet alloy cover 4140 Chromoly pressure plate Hardened steel wear posts High and low ratio pressure plate options Low inertia Serviceable components SFI certified design

Applications: - HONDA/CIVIC IV/1.2/1988.01-1991.12/D12B1 1187 Petrol 41 kW 56 BHP (1988.01 - 1991.12) , \n - HONDA/CIVIC IV/1.3 (EC8)/1987.10-1989.12/D13B1 1343 Petrol 55 kW 75 BHP (1987.10 - 1989.12) , \n - HONDA/CIVIC IV/1.3 (ED1)/1987.10-1989.12/D13B1 1343 Petrol 55 kW 75 BHP (1987.10 - 1989.12) , \n - HONDA/CIVIC IV/1.3 16V Cat (EC8)/1989.09-1991.09/D13B2 1343 Petrol 55 kW 75 BHP (1989.09 - 1991.09) , \n - HONDA/CIVIC IV/1.4 L (EC9)/1987.10-1989.12/D14A1 1396 Petrol 66 kW 90 BHP (1987.10 - 1989.12) , \n - HONDA/CIVIC IV/1.4 L (ED2)/1987.10-1989.12/D14A1 1396 Petrol 66 kW 90 BHP (1987.10 - 1989.12) , \n - HONDA/CIVIC IV/1.5/1988.01-1989.12/D15B1 1493 Petrol 60 kW 82 BHP (1988.01 - 1989.12) , \n - HONDA/CIVIC IV/1.5 i 16V (ED3)/1987.10-1991.09/D15B2, D15B3 1493 Petrol 69 kW 94 BHP (1987.10 - 1991.09) , \n - HONDA/CIVIC IV/1.5 i 16V (ED6)/1988.10-1991.09/D15B2 1493 Petrol 66 kW 90 BHP (1988.10 - 1991.09) , \n - HONDA/CIVIC IV/1.5 i 16V (ED6)/1988.10-1991.09/D15B2 1493 Petrol 69 kW 94 BHP (1988.10 - 1991.09) , \n - HONDA/CIVIC IV/1.6/1988.01-1989.12/D16Z5 1590 Petrol 91 kW 124 BHP (1988.01 - 1989.12) , \n - HONDA/CIVIC IV/1.6 i 16V (ED4)/1987.09-1991.09/D16A7 1590 Petrol 96 kW 130 BHP (1987.09 - 1991.09) , \n - HONDA/CIVIC IV/1.6 i 16V (ED7)/1987.10-1991.09/D16A6 1590 Petrol 80 kW 109 BHP (1987.10 - 1991.09) , \n - HONDA/CIVIC IV/1.6 i 16V (ED7)/1987.10-1991.09/D16Z2 1590 Petrol 81 kW 110 BHP (1987.10 - 1991.09) , \n - HONDA/CIVIC IV/1.6 i 16V 4x4 (EE5)/1989.10-1991.09/D16A6 1590 Petrol 80 kW 109 BHP (1989.10 - 1991.09) , \n - HONDA/CONCERTO (HW, MA)/1.4/1989.08-1991.10/D14A1, D14A8 1396 Petrol 66 kW 90 BHP (1989.08 - 1991.10) , \n - HONDA/CONCERTO (HW, MA)/1.4/1989.10-1992.10/D14A1 1396 Petrol 61 kW 83 BHP (1989.10 - 1992.10) , \n - HONDA/CONCERTO (HW, MA)/1.5 i 16V/1989.08-1995.03/D15B2 1493 Petrol 66 kW 90 BHP (1989.08 - 1995.03) , \n - HONDA/CONCERTO (HW, MA)/1.6/1989.10-1992.10/D16A9 1590 Petrol 96 kW 131 BHP (1989.10 - 1992.10) , \n - HONDA/CONCERTO (HW, MA)/1.6 16V/1989.08-1995.03/D16Z2 1590 Petrol 78 kW 106 BHP (1989.08 - 1995.03) , \n - HONDA/CONCERTO (HW, MA)/1.6 i 16V/1989.08-1995.03/D16Z2 1590 Petrol 82 kW 112 BHP (1989.08 - 1995.03) , \n - HONDA/CONCERTO (HW, MA)/1.6 i 16V (HW)/1989.08-1995.03/D16A8, D16Z1, D16Z4 1590 Petrol 90 kW 122 BHP (1989.08 - 1995.03) , \n - HONDA/CONCERTO sedan (HWW)/1.4/1989.08-1991.10/D14A1, D14A8 1396 Petrol 66 kW 90 BHP (1989.08 - 1991.10) , \n - HONDA/CONCERTO sedan (HWW)/1.4/1989.10-1992.10/D14A1 1396 Petrol 61 kW 83 BHP (1989.10 - 1992.10) , \n - HONDA/CONCERTO sedan (HWW)/1.5 i 16V/1989.08-1995.05/D15B2 1493 Petrol 66 kW 90 BHP (1989.08 - 1995.05) , \n - HONDA/CONCERTO sedan (HWW)/1.6/1989.10-1992.10/D16A9 1590 Petrol 96 kW 131 BHP (1989.10 - 1992.10) , \n - HONDA/CONCERTO sedan (HWW)/1.6 16V/1989.08-1995.03/D16Z2 1590 Petrol 78 kW 106 BHP (1989.08 - 1995.03) , \n - HONDA/CONCERTO sedan (HWW)/1.6 i 16V/1989.08-1995.03/D16A8, D16Z1, D16Z4 1590 Petrol 90 kW 122 BHP (1989.08 - 1995.03) , \n - HONDA/CONCERTO sedan (HWW)/1.6 i 16V/1989.08-1995.03/D16Z2 1590 Petrol 82 kW 112 BHP (1989.08 - 1995.03) , \n - HONDA/CRX II/1.4 GL/1990.01-1991.12/D14A1 1396 Petrol 66 kW 90 BHP (1990.01 - 1991.12) , \n - HONDA/CRX II/1.6 i 16V (ED9)/1987.10-1989.12/D16A8, D16A9 1590 Petrol 96 kW 131 BHP (1987.10 - 1989.12) , \n - HONDA/CRX II/1.6 i 16V (ED9)/1987.10-1992.02/D16Z5 1590 Petrol 91 kW 124 BHP (1987.10 - 1992.02) , \n - HONDA/LOGO/1.3 (GA3)/1999.03-2002.03/D13B7 1343 Petrol 48 kW 65 BHP (1999.03 - 2002.03) , \n - ROVER/200 coupe (XW)/216/1992.10-1999.06/D 16 A8 1590 Petrol 90 kW 122 BHP (1992.10 - 1999.06) , \n - ROVER/200 II Cabriolet (XW)/216 1.6/1990.04-1996.02/D 16 Z2 1590 Petrol 82 kW 111 BHP (1990.04 - 1996.02) , \n - ROVER/200 II Cabriolet (XW)/216 1.6i/1992.01-1999.11/D 16 A8 1590 Petrol 90 kW 122 BHP (1992.01 - 1999.11) , \n - ROVER/200 II liftback (XW)/216 GSi/1989.10-1995.10/D 16 A7 1590 Petrol 85 kW 116 BHP (1989.10 - 1995.10) , \n - ROVER/200 II liftback (XW)/216 GSi/1990.01-1995.12/D 16 Z2 1590 Petrol 82 kW 112 BHP (1990.01 - 1995.12) , \n - ROVER/200 II liftback (XW)/216 GTi/1990.01-1995.10/D 16 A8 1590 Petrol 90 kW 122 BHP (1990.01 - 1995.10) , \n - ROVER/200 II liftback (XW)/216 GTi/1990.09-1995.10/D 16 A9 1590 Petrol 96 kW 130 BHP (1990.09 - 1995.10) , \n - ROVER/400 II (XW)/416 GSI/1990.04-1995.04/D 16 Z2 1590 Petrol 82 kW 112 BHP (1990.04 - 1995.04) , \n - ROVER/400 II (XW)/416 GSI/GSE/1990.04-1995.04/D 16 A7 1590 Petrol 85 kW 116 BHP (1990.04 - 1995.04) , \n - ROVER/400 II (XW)/416 GTI/1990.04-1995.04/D 16 A8 1590 Petrol 90 kW 122 BHP (1990.04 - 1995.04) , \n - ROVER/400 II (XW)/416 GTI/GTE/1990.04-1995.04/D 16 A9 1590 Petrol 96 kW 131 BHP (1990.04 - 1995.04) , \n - ROVER/400 Tourer (XW)/1.6 i/1994.05-1998.11/D 16 A8 1590 Petrol 90 kW 122 BHP (1994.05 - 1998.11) , \n - ROVER/400 Tourer (XW)/1.6 i/1994.05-1998.11/D 16 Z2 1590 Petrol 82 kW 112 BHP (1994.05 - 1998.11) ,
