Extreme Clutch

SKU:KSZ18521-1E

-1E
	The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.
	Ø184mm Light Diaphragm (2.6mm) Ø184mm Heavy Diaphragm (2.8mm) Clamping Force 950kg 1080kg Torque Rating 535Nm (395ft.lbs) 610Nm (450ft.lbs) Bearing Contact Diameter 44-52mm 44-52mm Bearing Load (@ 48mm) 210kg 260kg Release Travel Required 5mm 5mm Assembly Mass (without flywheel) 3.10kg 3.10kg Disc Set Static Mass 0.6kg Friction Thickness New 6.35mm (0.250") 6.35mm (0.250") Friction Thickness Worn 5.58mm (0.220") 5.58mm (0.220") Product Features: Push type billet alloy cover 4140 Chromoly pressure plate Hardened steel wear posts High and low ratio pressure plate options Low inertia Serviceable components SFI certified design

Applications: - SUZUKI/IGNIS I (FH)/1.5 (HV81. RG415)/2003.08-2005.12/M15A 1490 Petrol 83 kW 113 BHP (2003.08 - 2005.12) , \n - SUZUKI/IGNIS I (FH)/1.5 Sport (RG415)/2003.12-2005.12/M15A 1490 Petrol 80 kW 109 BHP (2003.12 - 2005.12) , \n - SUZUKI/IGNIS II (MH)/1.5 (RM415)/2003.09-/M15A 1490 Petrol 73 kW 99 BHP (2003.09 -) , \n - SUZUKI/IGNIS II (MH)/1.5 4x4 (RM415)/2003.09-/M15A 1490 Petrol 73 kW 99 BHP (2003.09 -) , \n - SUZUKI/SWIFT III/1.3 (RS 413)/2005.02-2011/M13A 1328 Petrol 68 kW 92 BHP (2005.02 - 2011) , \n - SUZUKI/SWIFT III/1.5 (RS 415)/2005.02-2011/M15A 1490 Petrol 75 kW 102 BHP (2005.02 - 2011) ,
