Toyota 1JZ/ 2JZ (Transmission Samsonas) GM 26T x 1-1/8"" (28.6mm)

Toyota JZ to GM 26x28.6mm spline.

• Flat diaphragm
• Crank to finger 70.5mm
• Conversion Tremec CSC supplied

This kit has been designed and engineered to offer increased heat and torque capacity and is recommended for high performance Motorsport applications.

• Lightweight alloy pressure plate
• 2x rigid ceramic friction discs
• 4140 chromoly flywheel
• Concentric Slave Cylinder, flywheel/pressure plate bolts & alignment tool included
• 1830 Nm peak torque capacity
• Recommended for Motorsport applications

• Clutch Disc Diameter (mm)
  230
• Clutch Disc Spline Count
  26
• Clutch Disc Spline Diameter (mm)
  28.6
• Torque (Nm)
  1830
• Flywheel Step
  +3.8mm
• Design
  Twin Plate
• Stage
  Multiplate - track use only
• Tech Bulletins


• Clamp Load


• Recommended for
  Motorsport
• Ring Gear Tooth count


• Additional infotmation


• Weight [KG]:
  17.22
